Place of Origin:
Anhui, China
Brand Name:
Wayeal
Certification:
CE
Model Number:
SFJ-231
With its advanced communication interface, the Helium Leak Detector can easily connect to your existing equipment via RS232/485 or LAN. This allows for seamless integration into your existing system, making it a convenient and easy-to-use solution for helium leak detection systems.
The Helium Leak Detector is designed to operate under a maximum allowable leak detection pressure of 1500Pa. This makes it ideal for use in a variety of settings, from industrial facilities to research laboratories.
In addition to its impressive pressure capabilities, the Helium Leak Detector also boasts a mini leak detection rate of 5*10-13 Pa.m3/s in vacuum mode. This makes it one of the most sensitive helium leak detection systems available on the market today.
With its operating temperature range of 0~40°C, the Helium Leak Detector is versatile and can be used in a wide range of settings. Whether you're performing helium leak testing in a laboratory or industrial setting, this instrument is sure to provide reliable and accurate results every time.
This Helium Leak Detector is designed for helium leak detection and helium leak testing. It can detect quality 2, 3, 4 (H2, He3, He4) and comes with ion source consisting of 2pcs Iridium Coated Yttrium Oxide with automatic switching. The leak detection port is DN25KF and the unit measures 475 * 714 * 1168mm in size.
| Technical Parameters | Details |
|---|---|
| MES Interface | Standard |
| User Interface | 7inch Color Touch Screen |
| Operating temperature | 0~40°C |
| Mini Leak Detection Rate(Pa.m3/s)/Vaccum Mode | 5*10-13 Pa.m3/s |
| Detection Method | Helium Mass Spectrometer |
| Start Time (min) | ≤1.58min |
| Communication Interface | RS232/485, LAN |
| Language | Chinese/English |
| Detectable Quality | 2, 3, 4 (H2, He3, He4) |
| Product Name | Helium Leak Detector |
The Wayeal SFJ-231 Helium Leak Detector is designed to detect vacuum leaks using helium leak detection technology. This product is suitable for use in various applications, including refrigeration systems, air conditioning systems, automobile manufacturing, aerospace engineering, and many more. The product's ion source consists of 2pcs of iridium coated yttrium oxide, which allows for automatic switching. The response time of the product is less than 1 second, which makes it a highly efficient tool for detecting leaks.
The product's user interface consists of a 7-inch color touch screen, which makes it easy to operate and navigate. The leak detection port is DN25KF, which is a standard size that is compatible with most systems. The product's MES interface is also standard, which allows for easy integration with other systems.
The Wayeal SFJ-231 Helium Leak Detector is suitable for use in various scenarios and occasions. For example, it can be used in the manufacturing of air conditioning systems to detect leaks in the refrigerant system. It can also be used in the aerospace industry to detect leaks in the fuel system of aircraft. The product is also suitable for use in the automotive industry to detect leaks in the engine or transmission system.
Overall, the Wayeal SFJ-231 Helium Leak Detector is a reliable and efficient product that is suitable for use in various industries and applications. Its high sensitivity and fast response time make it an ideal tool for detecting leaks in vacuum systems. The product's ion source and user interface also make it easy to operate and integrate with other systems.
Our product also comes with a range of customization services to meet your specific needs. We offer language options in both Chinese and English, as well as a standard MES interface and I/O input output interface with 8 inputs and 8 outputs. Plus, with CE certification and a minimum order quantity of just one unit, you can trust that our product is of the highest quality.
Our pricing is negotiable, and we offer wooden case packaging for safe delivery. With a supply ability of 200 units per month and a delivery time of just 35 days, we're committed to providing our customers with the best possible service.
Don't settle for anything less than the best when it comes to helium leak detection. Choose Wayeal for reliable, high-quality products and unbeatable customer service.
The Helium Leak Detector product technical support and services include:
- Installation guidance and assistance
- Product training for users and operators
- Troubleshooting assistance and support
- Repair and maintenance services
- Calibration and certification services
- Upgrade and retrofit options
- Technical documentation and manuals
