Place of Origin:
Anhui, China
Brand Name:
Wayeal
Certification:
CE
Model Number:
SFJ-16D
Introduction of Helium Leak Detector:
The helium leak detector is an advanced diagnostic tool that employs cutting-edge technology to ensure high-precision detection of leaks in a variety of vacuum systems and sealed compartments. This device is often referred to as a Helium mass spectrometer Leak Detector due to its utilization of mass spectrometry for the identification of helium ions, which in turn indicates the presence of a leak.
Technical Parameters of Helium Leak Detector:
|
1800Pa Precision Vaccum Helium Leak Detector Machine Price 220V |
|
|---|---|
|
Product Name |
Helium Leak Detector |
| Detection Method | Helium Mass Spectrometer |
| Leak Detection Port | DN25KF |
| Leak Rate Display | Numbers, Bar Charts, Graphs |
| Response Time(s) | <1s |
| User Interface | 7inch Color Touch Screen |
| Operating temperature | 0~40°C |
| Max Allowable Leak Detection Pressure (Pa) | 1800 |
| Communication Interface | RS232/485, LAN |
| Detectable Quality | 2, 3, 4 (H2, He-3, He-4) |
| Mini Leak Detection Rate(Pa·m3/s)/Sniffer Mode | 5.0*10 -13 Pa·m3/s |
| Mini Leak Detection Rate(Pa·m3/s)/Vacuum Mode | 2.5*10-9 Pa·m3/s |
| Startup Time (min) | ≤1.58 |
| Backing Pump | Scroll Vacuum Pump |
| Diamension | 475*714*1168mm |
| Power Supply | AC220V, 50Hz/60Hz |
| Language | Chinese/English |
Aerospace: Ensuring the integrity of fuel systems, oxygen supply lines, and other critical components is paramount in aerospace applications.
Automotive: In the automotive industry, helium leak testing is used for testing fuel tanks, radiators, air-conditioning systems.
Medical Devices: Ensuring the sterility and integrity of medical implants, surgical instruments, and other devices is crucial, making helium leak testing an ideal choice.
Battery: In the energy industry, helium leak testing is used to test the integrity of the battery pack, battery housing, and even pouches and cells to prevent leaks and ensure safety.
Military: In military applications, helium leak testing is vital for ensuring the reliability of weapons systems, communication equipment, and vehicles. The method is used to detect leaks in everything from missile casings to submarine hulls, contributing to national security.
Methods of Helium Leak Detection (Helium Leak Detector)
Helium Vacuum Method
Helium Hood Method
Negative Pressure Method
Vacuum Chamber Helium Leak Detection and Recovery System (external filling)
Sniffer Method
